Ocularc 3.5 New Construction Housing Round

Features

• Housing only. Exterior trim sold separately
• Aperture Size: 3.5″
• Construction: 20 Gauge cold rolled steel
• Voltage: 120-277V
• Color Temperature: 2700K, 3000K, 3500K, 4000K
• CRI: 90
• ELV Dimming: 100-1%
• 0-10V Dimming: 100-5%
• TRIAC Dimming: 100-1%
• IC Rated, Airtight
• Rated Life: 50000 Hours
• Shallow housing under 4in depth
• Single spot light source
• Adjustable LED light engine included with housing: Vertical Adjustment 0-30, Horizontal Adjustment 365
• Timless: Die-cast spackle frame included
• Accepts one optional honey comb louver or optical accessory
• Driver concealed within the fixture

Dimensions

• Aperture Size: 3.5″
• Cut Out: 4.25″
• Ceiling Thickness: 0.5″ – 1″

Lamping

• Integrated LED

Document

• Spec Sheet
• Instruction Sheet
